Backsplash Assembly
1. Open lid and remove the
two hinge covers by pushing
in on the side locking tab.
3. Push backsplash back while rotating
top of backsplash away from you to
disengage the rear cover from the two
retention clips.
2. Close Lid and remove the
two screws that secure the
backsplash to the washer.
Removal and Accessing Boards
14
