Hinges
Remove backsplash assembly including backsplash bottom and lid assembly.
Removal
Remove the 4 screws and pull the
hinge out from the bottom of the tub
cover
Wire tie
Location
Raise the top cover. Cut the wire
tie that supports the hose onto
the back tab of the hinge.
NOTE: Bulk dispense models will
have wire ties on both hinges.
