Schematic

Strip Circuits Not Common to all Models – Continuity And Heater Circuits

Continuity Circuit

NOTE: Water is needed in the tub to complete the continuity circuit between the heater

sheath and the thermistor. If water is not present in the tub, the heater will not come on.
