– 14 –
JVM1540 Smart Board
(Back Side)
(Front Side)
RY203
CN202
CN401
CN201
CN201 - Vent Motor
CN202 - Turntable Motor, Cooktop Lamp
CN401 - Hood TCO & Door Sensing Switch
RY203 - Secondary Relay (Power Relay)
