5–58 LM10 MOTOR PROTECTION SYSTEM – INSTRUCTION MANUAL
DEVICENET OPERATIONS CHAPTER 5: COMMUNICATIONS
F9: Auxiliary Sense 1 / Run1-Run2 Time Delays
Format: two bytes in format 0xHHLL, where LL is the auxiliary sense 1 time delay and HH is
the Run1-Run2 time delay (Run1-Run2 time delay for revisions 1.40 and lower only)
Byte LL range: 0x00 to 0xFA (i.e. 0.0 to 25.0 seconds), where 0x00 is disabled
Byte LL multiplying factor: 0.1 (i.e. actual = byte LL in decimal × 0.1 seconds)
Byte HH range: 0x00 to 0xB4 (i.e. 0 to 180 seconds)
F10: Auxiliary Sense 2 / Run2-Run1 Time Delays
Format: two bytes in format 0xHHLL, where LL is the auxiliary sense 2 time delay and HH is
the Run2-Run1 time delay (Run2-Run1 time delay for revisions 1.40 and lower only)
Byte LL range: 0x00 to 0xFA (i.e. 0.0 to 25.0 seconds), where 0x00 is disabled
Byte LL multiplying factor: 0.1 (i.e. actual = byte LL in decimal × 0.1 seconds)
Byte HH range: 0x00 to 0xB4 (i.e. 0 to 180 seconds)
F11: Auxiliary Relay Faults (16-bit bitmask)
F12: Starter Type
Format: two bytes in format 0xHHLL, where LL is the motor type and HH is reserved
Byte LL enumeration:
F13: CT Turns
Format: two bytes in format 0xHHLL, where LL is the number of CT turns and HH is
reserved
2 90 A sensor pack 10 300:5
3 75:5 11 400:5
4 100:5 12 500:5
5 120:5 13 600:5
6 150:5 14 700:5
7 200:5 15 800:5
8 225:5
Bitmask Fault
---- ---- ---- ---1 Overcurrent
---- ---- ---- --1- Reserved
---- ---- ---- -1-- Jam
---- ---- ---- 1--- Stall
---- ---- ---1 ---- Current unbalance
---- ---- --1- ---- Aux sense
---- ---- -1-- ---- Load loss
---- ---- 1--- ---- Reserved
---- ---1 ---- ---- Reserved
---- --1- ---- ---- DeviceNet
---- -1-- ---- ---- Voltage range
Value Starter Type
0 FVNR (full voltage non-reversing)
1 FVR (full voltage reversing)
2 RV (reversing)
3 2S1W (two-speed one winding; Run-2, 4:1 ratio of Run-1)
4 2S2W (two-speed two winding; Run-2, 2:1 ratio of Run-1)
5Custom
Value CT Ratio Value CT Ratio
