CHAPTER 5: COMMUNICATIONS DEVICENET OPERATIONS
LM10 MOTOR PROTECTION SYSTEM – INSTRUCTION MANUAL 5–59
Byte LL range: 0x01 to 0x04 (i.e. 1 to 4 turns)
F14: Other Settings (16-bit Bitmask)
F15: Poll Data Group (enumeration; 16-bit unsigned integer)
F16: Run1-Run2 and Run2-Run1 Time Delay (16-bit unsigned integer)
Range: 0x0000 to 0x0258 (i.e. 0 to 600 seconds)
F17: Trip Class
Format: two bytes in format 0xHHLL, where LL is the trip class and HH is reserved
Byte LL enumeration:
F18: MAC ID
Format: two bytes in format 0xHHLL, where LL is the MAC ID and HH is reserved
Byte LL range: 0x00 to 0x3F (i.e. 0 to 63)
F19: Baud Rate (enumeration: 16-bit unsigned integer)
Range: 0x007D, 0x00FA, 0x01F4 (i.e. 125, 250, and 500 kbps)
F20: Cause of Trip (16-bit bitmask)
Bitmask Other Settings
---- ---- ---- ---1 Maintained input switch
---- ---- ---- --1- Auto restart
---- ---- ---- -1-- Under/overvoltage enable
---- ---- ---- 1--- DeviceNet fault
---- ---- ---1 ---- Reserved
---- ---- --1- ---- Reserved
---- ---- -1-- ---- Reserved
---- ---- 1--- ---- Reserved
---- ---1 ---- ---- 50 Hz system on
Value Poll Group
1 Poll 1 (7 bytes)
2 Poll 2 (12 bytes)
3 Poll 3 (22 bytes)
4 Poll 4 (7 bytes)
Value Trip Class
0A Trip class 10
0F Trip class 15
14 Trip class 20
1E Trip class 30
Bitmask Cause of Trip
---- ---- ---- ---1 No trip
---- ---- ---- --1- Overcurrent
---- ---- ---- -1-- Ground fault
---- ---- ---- 1--- Jam
---- ---- ---1 ---- Stall
---- ---- --1- ---- Current unbalance
---- ---- -1-- ---- Aux sense
---- ---- 1--- ---- Load loss
---- ---1 ---- ---- Reserved
---- --1- ---- ---- DeviceNet stop
