GE HEALTHCARE PROPRIETARY TO GE
D
IRECTION 5394227, 12 LOGIQ S8/LOGIQ E8 SERVICE MANUAL
Section 3-10 - Printer Installation 3 - 57
3-10-1-4 BW Printer setup summary
Win* = Windows Printer Setting, L=Landscape/P=Portrait
Util** = LOGIQ Utility Printer Setting, L=Landscape/P=Portrait
Table 3-6 Setup Summary
System Printer Size Win* Util**
Print Size
(approx) Note
R1 UP-D897 960x1280 P P Medium Previous Service Manual recommendation
1920x1280 P P Medium New recommendation
1920x1280 L L Large
UP-D898 N/A N/A N/A N/A R1 uses UP-D897 emulation
R2 UP-D897 960x1280 P P Medium Previous Service Manual recommendation
1920x1280 P P Medium Recommended
1920x1280 L L Large
UP-D898 960x1280 P P Very small Unfit for use
1920x1280 P P Medium Recommended
1920x1280 L L Large
R3 Upgrade UP-D897
UP-D898
960x1280 P P Small or Medium Not recommended on UP-D898
1920x1280 P P Medium Recommended (Monitor size same as R1/R2)
1920x1280 L L Large
R3 UP-D897
UP-D898
960x1280 P P Small or Medium Not recommended on UP-D898
1920x1280 P P Medium Slightly smaller image compared to R1/R2
1920x1280 L L Large Recommended if “Wide” is too small.
R4/R4.2.5x UP-D897
UP-D898
960x1280 P P Small or Medium Not recommended on UP-D898
1920x1280 P P Medium Slightly smaller image compared to R1/R2
1920x1280 L L Large Recommended if “Wide” is too small.
