GE HEALTHCARE

DIRECTION 5394152, Revision 5

LOGIQ™ P6/P6 PRO SERVICE MANUAL

Page 8-144 Section 8-4 - Software Installation

8-6-2-1 Perform Software Reloading in the Service Platform (cont’d)

3.) Press “Time Zone”

4.) Register the current Time Zone

5.) Press “Cancel”.

6.) Log onto the Service Platform.

7.) Go to “Utilities”->”Common Utilities”.

8.) Go to “Utility”->”System”->”About”

Verify that Software version and software build version are same with the ones before the Software

Reloading.

Figure 8-216 Time Zone

Current Time Zone

Table 8-1 Current Time Zone
