Edit Protocols Options: Operating Steps
7-6 MAC 5000 System — 2000657-057, Revision B
2. Select Return when you are finished changing the
Protocol name, Menu name, etc. The first phase screen
(usually called PRE-TEST) appears. The table below
explains each column of the PRE-TEST phase screen.
Pre-Test Phase Screen
Column What Does This Column Allow You to Do?
Stage Create multiple stages for each phase, except TEST-
END where only one stage is allowed.
Duration Set the duration of each stage. You may choose from
00:00-99:59 (minutes and seconds), or infinite duration.
The last stage always has an infinite duration. This
means that your MAC 5000 remains in the last stage for
an infinite duration, or until you stop the exercise test.
Ergometer
or
Set the ergometer workload in Watts or KPM.
n
Select from 0 to 1000 Watts (5 watt increments.)
n
Select from 0 to 6000 KPM (25 KPM increments.)
Treadmill Set the treadmill speed in MPH or Km/h:
n
Select from 0.0 to 25.0 MPH (0.1 MPH increments)
n
Select from 0.0 to 40.0 Km/h (0.1 Km/h increments)
Set the treadmill grade:
n
Select from 0.0 to 40.0 percent (0.1 percent
increments)
Report Print reports during a stage automatically.
n
Style sets the type of report that prints. You may
choose No Report, 12 Ld, Medians, or a 5 second
Rhythm report.
n
First indicates when the first report prints.
n
Repeat indicates the frequency the reports print after
the first report prints.
BP Set blood pressure prompting during a stage.
n
First indicates when the first blood pressure prompt
occurs.
n
Repeat indicates the frequency of blood pressure
prompts after the first prompt occurs.
Median Set how often Median complexes are saved during a
stage for the final report.
n
First indicates when the first Median is saved.
n
Repeat indicates how often Median complexes are
saved after the first Median complex is saved.
Column What Does This Column Allow You to Do?
