GE MAC 5000 Operator's Manual

Equipment Overview: Getting Started
MAC 5000 System — 2000657-057, Revision B 2-19
Software Description
Start Up Screen
Main Menu
Use the Main Menu to select the different functions
available on this system. The functions displayed in your
Main Menu may vary due to the installation of purchased
software options.
B C D
Press ECG to record an ECG
MAC5000 XXXX
E
A
BPM
***
***
I
II
III
aVR
aVL
aVF
V1
V2
V3
V4
V5
V6
157A
Name Description
A software version Displays the system’s software version
during the first few seconds of power up.
B user prompts Provides additional information.
C function icon Indicates the Main Menu function the system
is using. This is the Resting ECG function.
D battery status icon Indicates how much charge the battery has
available.
E menu Provides access to additional settings or
functions.
