GE MAC 5000 Operator's Manual

Defining the System Setup: Define the Exercise Test Setup (Option)
14-24 MAC 5000 System — 2000657-057, Revision B
Define the Exercise Test Setup (Option)
Miscellaneous Setup
Select this function to define your system’s basic exercise
test set up items.
Patient Data/Questions
Select this function to define two Yes/No and two alpha-
numeric patient data prompts.
Item Description
Timeout Interval The time it takes for a menu or prompt to “disappear”
from the screen when it is not being used. You may
type in a value between 15 and 600 seconds.
Cubic Spline Select Yes to turn on the baseline control option.
Event names: This allows you to create a list of event names, any of
which may be selected to label a patient episode
during an exercise test.
Reason for
Termination:
This allows you to create a list of reasons for
termination of the exercise test. Select the appropriate
reason at the end of the test.
System Setup
Exercise Test
Exercise Test
Miscellaneous Setup
168A, 057A
Item Description
Max Pred HR Select Yes to ask the patient’s maximum predicted heart
rate.
Target Heart
Rate
Select Yes to ask the patient’s target heart rate. Enter
the percentage of maximum predicted heart rate.
Extra questions In addition to the patient questions defined under Basic
System, there are 2 patient data prompts that you can
define. Each of the prompts can be answered in 3 ways:
n Numbers and letters = the answer to the prompt can
be made up of numbers and letters.
n Numbers only = the answer to the prompt can only be
in numbers.
n Yes or No = the answer to the prompt must be yes or
no.
System Setup
Exercise Test
Exercise Test
Patient Data
168A, 057A
