Defining the System Setup: Define the ECG Setup
14-18 MAC 5000 System — 2000657-057, Revision B
Suppress
ABNORMAL and
BORDERLINE
statements
Select Yes to prevent the Abnormal ECG and
Borderline ECG 12SL analysis statements from
appearing on printed, stored, and transmitted ECG
reports.
Pacemaker pulse
enhancer
Select Yes to detect very small pacemaker pulses.
However, when Pacemaker pulse enhancer is on, the
system should NOT be close to equipment emitting
high frequency radiation. High frequency radiation can
interfere with pacemaker pulse detection.
Preview before
analysis
Select Yes to allow the user to always preview a
recorded ECG before the system analyzes the data.
Storage format Choose the data compression format of the ECGs
stored on a MUSE CV system:
n
Select 500 Hz (MUSE Network) to transmit ECGs
to a MUSE CV system using MUSE software
versions 004A or later.
áThe Storage format item does not display if the
MAC 5000 has the ACI-TIPI option installed. With
ACI-TIPI, you can only store 500 Hz ECGs.
Item Description
Auto ECG
storage
Choose the ECGs you want your system to
automatically store to a disk:
n
Select All ECGs to automatically store a recorded
ECG.
n
Select No ECGs to disable automatic storage of a
recorded ECG.
n
Select Only ABNORMAL ECGs to automatically
store a recorded ECG that the 12SL analysis
program has classified as abnormal.
Auto ECG
transmission
Choose the ECGs you want your system to
automatically transmit:
n
Select All ECGS to automatically transmit a
recorded ECG.
n
Select No ECGS to disable automatic transmission
of a recorded ECG.
n
Select Only ABNORMAL ECGs to automatically
transmit a recorded ECG that the 12SL analysis
program has classified as abnormal.
Enable ACI-TIPI Select No to disable the ACI-TIPI function.
Select Yes to enable the ACI-TIPI function.
áThis is an option and might not be installed on your
unit.
Item Description
