Defining the System Setup: Define the ECG Setup
14-22 MAC 5000 System — 2000657-057, Revision B
Confirmed Reports Unconfirmed Reports
Item Description
Report formats Choose the report formats you want to print after an
ECG has been confirmed.
n
Select whether you want the report to print with or
without interpretation (12SL analysis statements).
n
Type a value between 0 and 10 for the number of
copies you want to print for each report format.
Item Description
Normal ECG
Reports
Choose the report formats your system automatically
prints after you press ECG.
n
Select whether you want the report to print with or
without interpretation (12SL analysis statements).
n
Type in the number of copies you want to print for
each report format.
Abnormal ECG
Reports
Choose the report formats your system automatically
prints when an abnormal ECG is detected.
n
Select whether you want the report to print with or
without interpretation (12SL analysis statements).
n
Type in the number of copies you want printed.
Confirmation text Choose the text that appears on an ECG report that
indicates the status of the ECG.
n
Select Unconfirmed to indicate that the ECG report
is not confirmed by a physician. Once an ECG is
confirmed, the word Confirmed appears on the
ECG report.
n
Select Reviewed by to display the reviewer’s name
on a confirmed ECG report. If the ECG report is not
confirmed, then no name appears.
