GE MAC 5000 Operator's Manual

Appendix E – Report Formats: Format Description
E-6 MAC 5000 System — 2000657-057, Revision B
Hi-Res or PHi-Res Signal
Overlapped
X,Y,Z data at two different amplitudes.
RMR One median complex for each of the 12 leads combined with 10 seconds of 3-lead rhythm.
Swedish Format 1 One median complex for each of the 12 leads at writer speed of 50mm/s combined with 5 seconds of 6-lead rhythm at half
writer speed. Text is on the bottom of the page.
Swedish Format 2 5 seconds for each of the 12 leads at writer speed 50mm/s. Text is on the top of the page.
Vector Loops Sagittal, horizontal, and frontal plane vectorgrams. Marks on sample X,Y,Z complexes identify P onset and offset, Q onset
and offset, and T onset.
Report Name Description
