Page #130 background imageLoading...
Page #130 background image
5-26 MAC 5500 resting ECG analysis system Revision E
2020299-020
Maintenance: Functional Checkout Procedures
Tools
1. ECG Simulator
2. Standard hand tools including a #10 and a #6 Torx Driver
3. Current Leakage Tester
4. Anti-static wrist strap
5. Applicable Service and/or Operator Manual
as needed for referenc
e
6. Floppy Diskette or SD Card
Wireless Serial Server 1,2,5 9 1,3,5
LAN (Comm PCB) 1,2,5 9 1,3,5,19
Barcode Reader 1,2,5 9 1,3,8
Mag Card Reader 1,2,5 9 1,3,9
Treadmill or Ergometer I/F Cable 1,2,5 9 1,3,6
Blood Pressure Monitor 1,2,5 9 1,3
Table 4. Option Repairs (Continued)
FRU / Option
Tools Visual Inspection
Checkout Procedure(s)
Table 5. Non-FRU Repairs
Description Tools Visual Inspection Checkout Procedure(s)
No Parts Replaced 1,5 1,2,3,4,5,6,7 1,3,4
*5 through 9
Software Update 1,5,6 N/A 1,2,3,4
*5 through 9
Hardware Upgrade 1,2,4,5 9,10 1,2,3,4,20
*5 through 9
Annual Electrical Safety Checkout 1,2,3,5 7,9,10 20, 1,2,3
