3-6 MAC 5500 resting ECG analysis system Revision E
2020299-020
Installation: Preparation for Use
Installing the MAC 5500 resting ECG analysis system
To secure the MAC 5500 to the trolley assembly, follow these steps:
1. Lock the wheels to prevent the trolley from rolling.
2. Remove the end panel by pulling out and up.
3. Place the unit on the trolley surface, then slide it on un
til the unit is firmly in
place and under the tab at the rear of the on the tray.
