Revision E MAC 5500 resting ECG analysis system 2-15
2020299-020
Equipment Overview: Theory of Operation
A copy of the primary boot program (pages with ID “Bn” where n is the 3-bit PCB
ID code 1-8) is kept in NAND flash. This is updated whenever a software update
happens. For -006 and -007 boards, the FPGA image and Primary boot code image
ID’s are X3 and B3 respectively.
The primary boot program can do a forceful software update, even if a valid
program is present in the NAND Flash, by using a special SD Card, which has a file,
update.com, in the root directory. The service menu provides a provision to update
the SPI data flash with the primary boot program copy residing the NAND Flash.
FPGA Internal Logic
All of the MAC 5500 resting ECG analysis system’s proprietary hardware is
contained in a single Xilinx FPGA that contains:
XBus Controller
Video Interface
LCD Controller with SDRAM frame buffer
Video Waveform Scroller
Interrupt Controller
System Interrupt Generator
Acquisition Module Interface
Thermal Printhead Interface
Serial EEPROM Interface
BBus Interface
Four PWM Analog Outputs
Beep Generator
On On Error - Could not program all the image files
as well as
the status page 'Z0'.
On Flashing Error - Could not program all the image files.
But the status page 'Z0' updated successfully
DS1 Red DS2 (Green) Status
