GE MULTILIN 269 MOTOR MANAGEMENT RELAY Series

3 SETUP AND USE Actual Values, Pg. 6
Page Line Information Line Description
3-14
6 1
PAGE 6: ACTUAL VALUESPAGE 6: ACTUAL VALUES
LEARNED PARAMETERSLEARNED PARAMETERS
ACTUAL VALUES page 6 header.
2
LEARNED Istart (AVG.OF 4LEARNED Istart (AVG.OF 4
STARTS) = XXX AMPSSTARTS) = XXX AMPS
Learned average motor starting current of 4
starts.
3
LEARNED Istart (last one) =LEARNED Istart (last one) =
XXX AMPSXXX AMPS
Learned motor starting current from last start.
4
END OF PAGE SIXEND OF PAGE SIX
ACTUAL VALUESACTUAL VALUES
Last line of page 6.
