Digital Counter
The above selections will be shown if the SPARE SW FUNCTION, EMERGENCY FUNCTION,
DIFF SW FUNCTION, or SPEED SW FUNCTION setpoints are set to “Digital Counter”. Refer to
the individual sections for Spare Switch, Emergency Restart, Differential Switch, Speed
Switch, or Remote Reset below for additional function-specific setpoints.
Only one digital input may be selected as a digital counter at a time. User defined units
and counter name may be defined and these will appear on all counter related actual
value and alarm messages. To clear a digital counter alarm, the alarm level must be
increased or the counter must be cleared or preset to a lower value.
Waveform Capture
The Waveform Capture setting for the digital inputs allows the 369 to capture a waveform
upon command (contact closure). The captured waveforms can then be displayed via the
EnerVista 369 Setup program.
DeviceNet Control
This function is available for the DeviceNet option only. The digital input set with the
DeviceNet control function and the switch status closed allows motor start, motor stop,
and fault reset commands through DeviceNet communications.
xxxxx SW FUNCTION:
Digital Counter
COUNTER
NAME: Counter
Range: 8 character alphanumeric
Only seen if function is Digital Counter
MESSAGE
COUNTER
UNITS: Units
Range: 6 character alphanumeric
Only seen if function is Digital Counter
MESSAGE
COUNTER
TYPE: Increment
Range: Increment, Decrement
Only seen if function is Digital Counter
MESSAGE
DIGITAL COUNTER
ALARM: Off
Range: Off, Latched, Unlatched
Only seen if function is Digital Counter
MESSAGE
ASSIGN ALARM RELAYS:
Alarm
Range: None, Alarm, Aux1, Aux2, or combinations.
Only seen if function is Digital Counter
MESSAGE
COUNTER ALARM LEVEL:
100
Range: 0 to 65535 in steps of 1
Only seen if function is Digital Counter
MESSAGE
RECORD ALARMS AS
EVENTS: No
Range: No, Yes
Only seen if function is Digital Counter
