GE Multilin 369

4–56 369 MOTOR MANAGEMENT RELAY – QUICKSTART GUIDE
S11 369 TESTING CHAPTER 4: KEYPAD SETPOINTS
4.9.2 Test Analog Outputs
PATH: S11 369 TESTING ØØ TEST ANALOG OUTPUTS
The Test Analog Output setpoints may be used during startup or testing to verify that the
analog outputs are functioning correctly. It may also be used when the motor is running to
give manual or communication control of an analog output. Forcing an analog output
overrides its normal functionality.
When the Force Analog Outputs Function is enabled, the output will reflect the forced value
as a percentage of the range 4 to 20 mA, 0 to 20 mA, or 0 to 1 mA. Selecting Off will place
the analog output channels back in service, reflecting the parameters programmed to
each.
TEST ANALOG OUTPUTS FORCE ANALOG
OUTPUT 1: Off
Range: Off, 1 to 100% in steps of 1
FORCE ANALOG
OUTPUT 2: Off
Range: Off, 1 to 100% in steps of 1
FORCE ANALOG
OUTPUT 3: Off
Range: Off, 1 to 100% in steps of 1
FORCE ANALOG
OUTPUT 4: Off
Range: Off, 1 to 100% in steps of 1
