4–54 369 MOTOR MANAGEMENT RELAY – QUICKSTART GUIDE
S10 ANALOG OUTPUTS CHAPTER 4: KEYPAD SETPOINTS
Reactive Power –32000 to 32000 kvar 1 0 750
Real Power –32000 to 32000 kW 1 0 1000
Apparent Power 0 to 65000 kVA 1 0 1250
Thermal Capacity
Used
0 to 100% 1 0 100
Relay Lockout Time 0 to 999 minutes 1 0 150
Motor Load 0.00 to 20.00 x FLA 0.01 0.00 1.25
MWhrs 0 to 65535 MWhrs 1 0 65535
Table 4–2: Analog Output Parameters
PARAMETER NAME RANGE /UNITS STEP DEFAULT
MINIMUM MAXIMUM
