GE Multilin G650 - Page 164

GEK-113285A G650 Generator Protection & Control System 5-21
5 SETTINGS 5.3 SYSTEM SETUP
5
In the flex curves menu there are 120 points to define a user curve. 40 points for reset (from 0 to 0.98 times the pickup
value) and 80 for operate (from 1.03 to 20 times the pickup).
