6-2 G650 Generator Protection & Control System GEK-113285A
6.2 STATUS 6 ACTUAL VALUES
6.2STATUS 6.2.1 OPERATION BITS
(Actual > Status > Operation bits)
OPERATION BIT 1...24 These 24 bits are the outputs of each possible Operation modules, programmed in menu
Setpoint > Relay Configuration > Operations. The light up LED indicates their status 1
(activation)
Table 6–2: OPERATION BITS
6.2.2 BREAKER
The signals associated to the opened or closed status of the breaker can be monitored at “Actual > Status > Breaker”
Table 6–3: BREAKER STATUS
BREAKER OPEN: Open breaker status. In the switchgear selected as breaker, besides providing the usual
switchgear contact status, the system provides also the open breaker, closed breaker, and
undefined breaker states.
BREAKER CLOSED: Breaker closed.
BREAKER UNDEFINED: If there are two digital inputs configured for breaker contacts 52/a and 52/b, this status will be
present when both inputs are at 0 or at 1. This status can be caused by a wiring failure, failure of
auxiliary elements, etc.
OPERATION BITS
OPERATION BIT 1
OPERATION BIT 2
…
OPERATION BIT 24
BREAKER STATUS
BREAKER OPEN
BREAKER CLOSED
BREAKER UNDEFINED
