GE Multilin G650 - Connections for Testing Protection Elements

GEK-113285A G650 Generator Protection & Control System 9-11
9 COMMISSIONING 9.9 CONNECTIONS FOR TESTING PROTECTION ELEMENTS
9
9.9CONNECTIONS FOR TESTING PROTECTION ELEMENTS
Connect current sources to the relay according to the wiring diagram. Current and voltage input terminals are as follows:
PHASE CONNECTIONS
Current
IA B1-B2
IB B3-B4
IC B5-B6
IG B9-B10
ISG B11-B12
Voltage
VI A5-A6
VII A7-A8
VIII A9-A10
VX A11-A12
