5-140 G650 Generator Protection & Control System GEK-113285A
5.8 RELAY CONFIGURATION 5 SETTINGS
Table 5–113: GRAPHIC AND TEXT EDITION SYMBOLS
GRAPHIC AND TEXT EDITION SYMBOLS
ICONS IN SCREEN DESCRIPTION AVAILABILITY
Ground symbols in different positions. The first two are not available in the
N model (IEC selection).
Voltage Transformers representation Only for standard model M.
Two and three winding voltage transformers
representation.
Only for N model (IEC selection)
Current transformer representation Only for N model (IEC selection).
Symbols reserved for future uses Both M and N selection
Symbol for capacitor banks. Both M and N selection
Symbol for vertical capacitor banks. Only for N model (IEC selection).
Symbol for wye connection Both M and N selection
Symbol for open delta and delta connection Both M and N selection
Display of a fix text up to 40 ASCII characters Both M and N selection
Auxiliary drawing lines Both M and N selection
