GEK-113285A G650 Generator Protection & Control System A-3
APPENDIX A A.1 LOGIC OPERANDS
A
Configurable Logic Outputs (512 elements)
VIRTUAL OUTPUT 000 Configurable logic output 000
VIRTUAL OUTPUT 001 Configurable logic output 001
... ...
VIRTUAL OUTPUT 511 Configurable logic output 511
Operation Bits (24 elements)
OPERATION BIT 1
Operation bit 001: (0) the configured time expires or
when success conditions are met;(1) operation 1 is
executed and interlocks are fulfilled.
OPERATION BIT 2
Operation bit 002: (0) the configured time expires or
when success conditions are met;(1) operation 2 is
executed and interlocks are fulfilled.
... ...
OPERATION BIT 24
Operation bit 024: (0) the configured time expires or
when success conditions are met;(1) operation 24 is
executed and interlocks are fulfilled.
