GEK-113285A G650 Generator Protection & Control System F-1
APPENDIX F F.1 FACTORY DEFAULT SETTINGS
F
APPENDIX F FACTORY DEFAULT CONFIGURATIONF.1 FACTORY DEFAULT SETTINGS
Factory Default Settings Example for Enhanced Models
PRODUCT SETUP>COMMUNICATION SETTINGS >SERIAL PORTS
SETTING DESCRIPTION NAME DEFAULT VALUE STEP RANGE
USER
VALUE
Baud rate for COM1 COM1 Baud Rate 19200 N/A [300 : 115200]
Baud rate for COM2 COM2 Baud Rate 19200 N/A [300 : 115200]
Parity for COM1 COM1 Parity NONE N/A [NONE:ODD:EVEN]
Parity for COM2 COM2 Parity NONE N/A [NONE:ODD:EVEN]
PRODUCT SETUP>COMMUNICATION SETTINGS >NETWORK (ETHERNET)
NETWORK (ETHERNET)1 > NETWORK (ETHERNET)2
SETTING DESCRIPTION NAME DEFAULT VALUE STEP RANGE
USER
VALUE
1st octec of IP address IP Address Oct1 0 N/A [0 : 255]
2nd octec of IP address IP Address Oct2 0 N/A [0 : 255]
3rd octec of IP address IP Address Oct3 0 N/A [0 : 255]
4th octec of IP address IP Address Oct4 0 N/A [0 : 255]
1st octec of Netmask Netmask Oct1 0 N/A [0 : 255]
2nd octec of Netmask Netmask Oct2 0 N/A [0 : 255]
3rd octec of Netmask Netmask Oct3 0 N/A [0 : 255]
4th octec of Netmask Netmask Oct4 0 N/A [0 : 255]
1st octec of Gateway Gateway IP Oct1 0 N/A [0 : 255]
2nd octec of Gateway Gateway IP Oct2 0 N/A [0 : 255]
3rd octec of Gateway Gateway IP Oct3 0 N/A [0 : 255]
4th octec of Gateway Gateway IP Oct4 0 N/A [0 : 255]
PRODUCT SETUP>COMMUNICATION SETTINGS >MODBUS PROTOCOL
SETTING DESCRIPTION NAME DEFAULT VALUE STEP RANGE
USER
VALUE
Slave address for COM1
Modbus Address
COM1
254 N/A [1 : 255]
Slave address for COM2
Modbus Address
COM2
254 N/A [1 : 255]
Modbus port number for Modbus TCP/
IP
Modbus Port Number 502 N/A [0 : 65535]
