GE Multilin G650 - Page 67

3-4 G650 Generator Protection & Control System GEK-113285A
3.3 MECHANICAL DESCRIPTION 3 HARDWARE
3
Figure 3–4: DRILLING DIMENSIONS DIAGRAM
NOTE: All dimensions are shown in mm
(
inches
)
.
ESC
F1
F2
*
237
( 9,30 )
169 ( 6,65 )
(1,38)
266,7 ( 10,50 )
260,7 ( 10,26 )
FRONT VIEW
SIDE VIEW
N
GE Multilin 650
186 ( 7,32 )
210 ( 8,27 )
190,5 ( 7,5 )
263 ( 10,36 )
4x O7 ( ,27 )
PANEL MOUNTING CUTOUT
