PRODUCT DESCRIPTION
2.2 ORDERING CODE
The information required to completely specify the relay is provided in the following table:
HID - -
APPLICATION
1
1 Winding Transformer REF – 1 resistor + 1 MOV
2
2 Winding Transformer REF – 2 resistors + 2 MOV
3
Busbar Application. High Impedance Differential Element
LATCHING RELAY / POWER SUPPLY
0
Without latching relay
1
48 Vdc Latching relay
2
125 Vdc Latching relay
3
220 Vdc Latching relay
2.3 TECHNICAL SPECIFICATIONS.
SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE.
2.3.1. VOLTAGE LIMITERS
TECNOLOGY: MOV (METAL OXYDE VARISTOR)
Rated Voltage (VDC):
Rated Voltage (VAC):
Rated Current (VDC):
Pick Voltage:
Pick Current:
Power Dissipation:
Rated Power Absorption:
350 V
290 V
4.7 mA ± 50%
1,900 V
10 A
8 W
5,400 J with latching relay
10,000 J without latching relay
2.3.2. STABILIZING RESISTORS
Models with latching relay 2kΩ 75W
Models without latching relay 1kΩ 100W
2-2 HID High Impedance Differential Module GEK-113064
