ACCEPTANCE TESTS
4.5 MEASURES
Latching relay coil resistor (only for latching relay option) :
Latching relay
option
Terminals A1 – A3 Terminals B10 – B12
1 (48 Vdc) 340 Ohm 340 Ohm
2 (125 Vdc) 2K15 2K15
3 (220 Vdc) 4K2 4K2
NOTE: An error of 20% will be admitted
Resistors Measure:
Check that the resistor value between terminals is:
• 2K with latching relay
• 1K without latching relay
NOTE: An error of 12% will be admitted
C12 – D8
C11 – D7
C10 – D6
Thyrites current measure:
Applied voltage
Thyrite Terminals
290 Vac
C12 – D4 2 - 10 mA
C11 – D3 2 – 10 mA
C10 – D2 2 - 10 mA
GEK-113064 HID High Impedance Differential Module 4-3
