GETTING STARTED
1.4.1. MOUNTING & WIRING
Please refer to the HARDWARE chapter for detailed device mounting and wiring instructions. Review all WARNINGS
and CAUTIONS.
1.4.2. FRONT PLATE BUTTON
The HID front plate incorporates a reset pushbutton to reset the latching relay once the fault has been cleared, in
order to eliminate the resistors short-circuit.
FIGURE 1-5 HID FRONT PANEL
1-6 HID High Impedance Differential Module GEK-113064
