AUXILIARY OUTPUT EVENT SELECTION
DATA EVENT DATA EVENT
0 Burglary alarm 30 Open period
1 Fire alarm 31 Closed period
2 24 hour alarm 32 Listen-in
3 Trouble alarm 33 Line seizure
4 Tamper alarm 34 Reserved
5 Yelping siren 35 Fail to communicate
6 Steady siren 36 Telephone line fault
7 Any siren 37 Program mode
8 Any bypass 38 Download in process
9 AC fail 39 Reserved
10 Low battery 40 Short circuit (overcurrent on 12
Vdc)
11 Duress 41 Box tamper
12 Aux 1 keypad (fire alarm) 42 Siren tamper
13 Aux 2 keypad (medical alarm) 43 Any open
14 Panic keypad 44 Any short
15 Keypad tamper 45 Any fault (open/short on non-fire
zone)
16 Autotest 46 Any alarm
17 Alarm memory (solid) 47 Beeping keypad
18 Entry
48♦
Code entry (see note below)
19 Exit
49♣
Key FOB function 1
20 Entry or exit
50♣
Key FOB function 2
21 Armed state 51 Always ON
22 Disarmed state 52 Autoarm warning time
23 Ready 53 Any siren when in away mode
24 Not ready 54 Progress of entry/exit (follows
keypad buzzer)
25 Fire 55 Auxiliary communication failure
26 Fire trouble 56 Radio test
27 Chime 57 Any siren when armed in any mode
28 Expander trouble 58 Alarm memory (pulsating)
29 Dynamic battery test time
Note :
♦
When event 48 is programmed, it is possible to program a user code authorisation to
select the output(s), which a particular code will activate. When LED 8 is on for an
authorisation, then LED’s -24 will correspond to the code that activates outputs 1 - 2
respectively. (See “Programming the LED Keypads”)
♣
Events 49 and 50 require one or more of the following to operate: wireless receivers or
cardreaders.
If set to follow condition, these events will be 1 second.
NX-8-EUR Installation manual Page 59 02/07/06
