18
NX-
320E Power Supply
LOC
PAGE
DESCRIPTION
DEFAULT
DATA
A/C Delay (in minutes)
5
___
18
15
Dynamic Battery Test (in minutes)
0
___
Device Options (Circle the numbers to program)
19
15
1=On for AC report always sent; Off follows control
2=On enables periodic battery test
3=On enables low battery reporting
4=On enables siren tamper/trouble reporting
5=Reserved
6=Reserved
7=Reserved
8=Reserved
17
19
Table of Contents
Table of Contents
3
General Description
4
Ordering Information
4
Underwriters Laboratories Information
4
Enclosure Diagram
5
Battery Calculation Table
5
Terminal Descriptions
6
Wiring Requirements
6
Layout
7
Addressing
8
Enrolling
8
Understanding the Leds
8
Programming
9
Using the Led Keypad
9
Using the Lcd Keypad
10
Programming Data
10
Location 0
11
Programming Event & Time for Output a
11
Location 1 Programming Special Features for Output a
12
Location 2 Programming the Event & Time for Output B
12
Location 3 Programming Special Features for Output B
12
Location 4 Programming the Event & Time for Output C
13
Locations 6 & 7 Reserved
13
Location 4
13
Codes 1-10 Output Enable
14
Location 8
14
Codes 11-20 Output Enable
14
Codes 21-30 Output Enable
14
Codes 31-40 Output Enable
14
Codes 41-50 Output Enable
14
Codes 51-60 Output Enable
14
Codes 61-70 Output Enable
15
Location 14
15
Codes 71-80 Output Enable
15
Codes 81-90 Output Enable
15
Codes 91-99 Output Enable
15
A/C Delay and Dynamic Battery Test
15
Device Options
15
Programming Worksheets
16
Specifications
20
