GE Interlogix
SERVICE MENU
The service icon will be “on” if the security system requires service.
If the service icon is “on”, press [
r
]-[
2
] to determine the service condition. If a zone(s) is tampered, the tamper icon will
flash and the zone icon(s) will be on. If a zone(s) is troubled, the trouble icon will flash and the zone icon(s) will be on.
If the service icon is flashing, one or more zone icon(s) will illuminate indicating what service(s) is required. Press the
[
•
] and [
–
] to scroll between tamper, trouble and other service conditions. Call your service provider immediately for
these problems. The following table provides a list of what each icon means in a service condition.
ICON PROBLEM
SYSTEM FAULT - Press the [1] key. The zone icon(s) that is
illuminated corresponds to the system fault(s) below:
1 Over Current Fault
2 Siren Trouble
3 Box Tamper
4 Expander Power
5 Expander Low Battery
6 Expander Box Tamper
7 Expander Trouble
8 Ground Fault
1
Note: Faults 1 & 2 are global in nature and will affect all
partitions of a multi-partition system. Press the [#] key to return
to the 1 of 8 service icons.
2 RESERVED
3
ZONE LOW BATTERY - Press the [3] key. The zone icon(s)
will illuminate showing which zone(s) has a low battery. This only
applies to wireless zones. Press the [#] key to return to the 1 of 8
service icons.
4
ZONE LOSS OF SUPERVISION - Press the [4] key and the
zone icon(s) will illuminate showing which zone(s) has loss of
supervision. This only applies to wireless zones. Press [#] key to
return to the 1 of 8 service icons.
5 RESERVED
TELEPHONE LINE TROUBLE/LINE CUT – Press the [6] key.
The zone icon(s) will illuminate as they correspond to these service
conditions:
1-5 = Reserved 6 = Telephone Line Trouble / Line Cut
7 = Aux communication device failure
6
The service icon will remain lit until the trouble clears and a user
code is entered. * SEE NOTE AT END OF TABLE.
7
FAILURE TO COMMUNICATE -
This icon will illuminate
when there is a failure to communicate between your system and
the central station. * SEE NOTE AT END OF TABLE.
8
LOSS OF SYSTEM TIME - This icon will illuminate when there
has been a loss of power and your system clock needs to be reset.
Refer to page Error! Bookmark not defined.. * SEE NOTE AT
END OF TABLE.
#
EXIT - Press the [#] key to exit the Service Menu.
* NOTE to Icons 6,7,8: This fault is global in nature and will affect all
partitions of a multi-partition system.
