Chapter 13: Digital Detector
Optima XR220amx X-Ray System 54400222-1EN Rev 1 DRAFT 11092010 13-16
Operator Manual © 2010 General Electric Company. All rights reserved.
Specifications
Detector Size and Weight
Table 13-9 Detector size and weight specifications
Environmental Contraints
This section describes the environmental conditions that the detector is designed to withstand.
CAUTION Operation or storage outside of these constraints may cause damage to the
detector.
Table 13-10 Environmental Constraints
Item Specification
Overall detector size
• Including handle
• Not including tether
Thickness: 27mm
Width:452mm
Height:580mm
Image Size
The active area of the x-ray panel
2024 x 2024 pixels or
40.4 x 40.4 cm
Weight
Not including the tether or grid
9.9lbs (without battery)
Battery: 0.38lbs
Item Operating Environment Constraints
Non Operating Environment
Constraints
This column contains additional
operating environmental constraints,
within which the subsystem function
and performance capabilities shall be
in compliance.
This column defines additional Non-
operating environmental constraints,
within which the subsystem function
and performance capabilities shall be
in compliance, when returned to the
operational state, within operating
environment conditions.
