Event Value Display
PSL CONFIG DOWNLOADED
PSL CONFG D/LOAD
B
Y {int} GROUP {grp}
SETTINGS DOWNLOADED
SETTINGS D/LOAD
B
Y {int} GROUP {grp}
PSL SETTINGS UPLOADED
PSL STNG UPLOAD
B
Y {int} GROUP {grp}
DNP SETTINGS UPLOADED
DNP STNG UPLOAD
B
Y {int}
TRACE DATA UPLOADED
TRACE DAT UPLOAD
B
Y {int}
IEC61850 CONFIG UPLOADED
IED CONFG UPLOAD
B
Y {int}
USER CURVES UPLOADED
USER CRV UPLOAD
B
Y {int} GROUP {crv}
PSL CONFIG UPLOADED
PSL CONFG UPLOAD
B
Y {int} GROUP {grp}
SETTINGS UPLOADED
SETTINGS UPLOAD
B
Y {int} GROUP {grp}
EVENTS HAVE BEEN EXTRACTED
EVENTS EXTRACTED
B
Y {int} {nov} EVNTS
ACTIVE GROUP CHANGED
ACTIVE GRP CHNGE
B
Y {int} GROUP {grp}
CS SETTINGS CHANGED
C & S CHANGED
B
Y {int}
DR SETTINGS CHANGED
DR CHANGED
B
Y {int}
SETTING GROUP CHANGED
SETTINGS CHANGED
B
Y {int} GROUP {grp}
POWER ON
POWER ON
-
SOFTWARE_DOWNLOADED
S/W DOWNLOADED
-
where:
● int is the inter
face definition (UI, FP, RP1, RP2, TNL, TCP)
● prt is the port ID (FP, RP1, RP2, TNL, DNP3, IEC, ETHR)
● grp is the group number (1, 2, 3, 4)
● crv is the Curve group number (1, 2, 3, 4)
● n is the new access level (0, 1, 2, 3)
● p is the password level (1, 2, 3)
● nov is the number of events (1 – nnn)
Each new event has an incremented unique number, therefore missing events appear as ‘gap’ in the sequence.
The unique identifier forms part of the event record that is read or uploaded from the IED.
Note:
It is no longer possible to clear Event, Fault, Maintenance, and Disturbance Records.
P54A/B/C/E Chapter 18 - Cyber-Security
P54xMED-TM-EN-1 429
