P54A/B/C/E
Appendix B - Settings and Signals
P54xMED-TM-EN-1
B227
ORDINAL SIGNAL NAME ELEMENT NAME
DESCRIPTION
58
Opto 27
DDB_OPTO_ISOLATOR_27
From opto input 27 - when opto energized
59
Opto 28
DDB_OPTO_ISOLATOR_28
From opto input 28 - when opto energized
60
Opto 29
DDB_OPTO_ISOLATOR_29
From opto input 29 - when opto energized
61
Opto 30
DDB_OPTO_ISOLATOR_30
From opto input 30 - when opto energized
62
Opto 31
DDB_OPTO_ISOLATOR_31
From opto input 31 - when opto energized
63
Opto 32
DDB_OPTO_ISOLATOR_32
From opto input 32 - when opto energized
64
IM Input 1
DDB_INTERIN_1
InterMiCOM Input 1 - is driven by a message from the remote line end
65
IM Input 2
DDB_INTERIN_2
InterMiCOM Input 2 - is driven by a message from the remote line end
66
IM Input 3
DDB_INTERIN_3
InterMiCOM Input 3 - is driven by a message from the remote line end
67
IM Input 4
DDB_INTERIN_4
InterMiCOM Input 4 - is driven by a message from the remote line end
68
IM Input 5
DDB_INTERIN_5
InterMiCOM Input 5 - is driven by a message from the remote line end
69
IM Input 6
DDB_INTERIN_6
InterMiCOM Input 6 - is driven by a message from the remote line end
70
IM Input 7
DDB_INTERIN_7
InterMiCOM Input 7 - is driven by a message from the remote line end
71
IM Input 8
DDB_INTERIN_8
InterMiCOM Input 8 - is driven by a message from the remote line end
72
IM Output 1
DDB_INTEROUT_1
InterMiCOM Output 1 - is an output to the remote line end
73
IM Output 2
DDB_INTEROUT_2
InterMiCOM Output 2 - is an output to the remote line end
74
IM Output 3
DDB_INTEROUT_3
InterMiCOM Output 3 - is an output to the remote line end
75
IM Output 4
DDB_INTEROUT_4
InterMiCOM Output 4 - is an output to the remote line end
76
IM Output 5
DDB_INTEROUT_5
InterMiCOM Output 5 - is an output to the remote line end
77
IM Output 6
DDB_INTEROUT_6
InterMiCOM Output 6 - is an output to the remote line end
78
IM Output 7
DDB_INTEROUT_7
InterMiCOM Output 7 - is an output to the remote line end
79
IM Output 8
DDB_INTEROUT_8
InterMiCOM Output 8 - is an output to the remote line end
80
IM64 R1 Input 1
DDB_IM64_R1_1_IN
IM64 R1 input 1 - is driven by a message from the remote line end
81
IM64 R1 Input 2
DDB_IM64_R1_2_IN
IM64 R1 input 2 - is driven by a message from the remote line end
82
IM64 R1 Input 3
DDB_IM64_R1_3_IN
IM64 R1 input 3 - is driven by a message from the remote line end
83
IM64 R1 Input 4
DDB_IM64_R1_4_IN
IM64 R1 input 4 - is driven by a message from the remote line end
84
IM64 R1 Input 5
DDB_IM64_R1_5_IN
IM64 R1 input 5 - is driven by a message from the remote line end
85
IM64 R1 Input 6
DDB_IM64_R1_6_IN
IM64 R1 input 6 - is driven by a message from the remote line end
86
IM64 R1 Input 7
DDB_IM64_R1_7_IN
IM64 R1 input 7 - is driven by a message from the remote line end
