Appendix B - Settings and Signals
P54A/B/C/E
B250
P54xMED-TM-EN-1
ORDINAL SIGNAL NAME ELEMENT NAME
DESCRIPTION
1052
FnKey LED7 Red
DDB_OUTPUT_TRI_LED_15_RED
Programmable function key LED 7 red is energized
1053
FnKey LED7 Grn
DDB_OUTPUT_TRI_LED_15_GRN
Programmable function key LED 7 green is energized
1054
FnKey LED8 Red
DDB_OUTPUT_TRI_LED_16_RED
Programmable function key LED 8 red is energized
1055
FnKey LED8 Grn
DDB_OUTPUT_TRI_LED_16_GRN
Programmable function key LED 8 green is energized
1056
FnKey LED9 Red
DDB_OUTPUT_TRI_LED_17_RED
Programmable function key LED 9 red is energized
1057
FnKey LED9 Grn
DDB_OUTPUT_TRI_LED_17_GRN
Programmable function key LED 9 green is energized
1058
FnKey LED10 Red
DDB_OUTPUT_TRI_LED_18_RED
Programmable function key LED 10 red is energized
1059
FnKey LED10 Grn
DDB_OUTPUT_TRI_LED_18_GRN
Programmable function key LED 10 green is energized
1060
LED1 Con R
DDB_TRI_LED_RED_CON_1
Assignment of input signal to drive output LED 1 red
1061
LED1 Con G
DDB_TRI_LED_GRN_CON_1
Assignment of signal to drive output LED 1 green. To drive LED 1 yellow DDB 1024 and DDB 1025 must be driven at the same time
1062
LED2 Con R
DDB_TRI_LED_RED_CON_2
Assignment of input signal to drive output LED 2 red
1063
LED2 Con G
DDB_TRI_LED_GRN_CON_2
Assignment of signal to drive output LED 2 green. To drive LED 2 yellow DDB 1026 and DDB 1027 must be driven at the same time
1064
LED3 Con R
DDB_TRI_LED_RED_CON_3
Assignment of input signal to drive output LED 3 red
1065
LED3 Con G
DDB_TRI_LED_GRN_CON_3
Assignment of signal to drive output LED 3 green. To drive LED 3 yellow DDB 1028 and DDB 1029 must be driven at the same time
1066
LED4 Con R
DDB_TRI_LED_RED_CON_4
Assignment of input signal to drive output LED 4 red
1067
LED4 Con G
DDB_TRI_LED_GRN_CON_4
Assignment of signal to drive output LED 4 green. To drive LED 4 yellow DDB 1030 and DDB 1031 must be driven at the same time
1068
LED5 Con R
DDB_TRI_LED_RED_CON_5
Assignment of input signal to drive output LED 5 red
1069
LED5 Con G
DDB_TRI_LED_GRN_CON_5
Assignment of signal to drive output LED 5 green. To drive LED 5 yellow DDB 1032 and DDB 1033 must be driven at the same time
1070
LED6 Con R
DDB_TRI_LED_RED_CON_6
Assignment of input signal to drive output LED 6 red
1071
LED6 Con G
DDB_TRI_LED_GRN_CON_6
Assignment of signal to drive output LED 6 green. To drive LED 6 yellow DDB 1034 and DDB 1035 must be driven at the same time
1072
LED7 Con R
DDB_TRI_LED_RED_CON_7
Assignment of input signal to drive output LED 7 red
1073
LED7 Con G
DDB_TRI_LED_GRN_CON_7
Assignment of signal to drive output LED 7 green. To drive LED 7 yellow DDB 1036 and DDB 1037 must be driven at the same time
1074
LED8 Con R
DDB_TRI_LED_RED_CON_8
Assignment of input signal to drive output LED 8 red
1075
LED8 Con G
DDB_TRI_LED_GRN_CON_8
Assignment of signal to drive output LED 8 green. To drive LED 8 yellow DDB 1038 and DDB 1039 must be driven at the same time
1076
FnKey LED1 ConR
DDB_TRI_LED_RED_CON_9
Assignment of signal to drive output function key LED 1 red. This LED is associated with function key 1
1077
FnKey LED1 ConG
DDB_TRI_LED_GRN_CON_9
Assignment of signal to drive output function key LED 1 green. This LED is associated with function key 1. To drive function key LED, yellow
DDB 1040 and DDB 1041 must be active at the same time
1078
FnKey LED2 ConR
DDB_TRI_LED_RED_CON_10
Assignment of signal to drive output function key LED 2 red. This LED is associated with function key 2
1079
FnKey LED2 ConG
DDB_TRI_LED_GRN_CON_10
Assignment of signal to drive output function key LED 2 green. This LED is associated with function key 2. To drive function key LED, yellow
DDB 1042 and DDB 1043 must be active at the same time
