9 SCADA Communications
P253/EN M/C
9-19
2.3.3 Implementation Table
The following table identifies the variations, function codes, and qualifiers supported by the P253 in
both request messages and in response messages.
For static (non-change-event) objects, requests sent with qualifiers 00, 01, 06, 07, or 08, will be
responded with qualifiers 00 or 01. Static object requests sent with qualifiers 17 or 28 will be
responded with qualifiers 17 or 28. For change-event objects, qualifiers 17 or 28 are always
responded.
Sends Unsolicited Responses:
 Never
 Configurable (attach
explanation)
 Only certain objects
 Sometimes (attach
explanation)
 ENABLE/DISABLE
UNSOLICITED Function
codes supported
Sends Static Data in Unsolicited Responses:
Never
When Device Restarts
When Status Flags Change
No other options are permitted.
Default Counter Object/
Variation:
No Counters Reported
Configurable (attach
explanation)
Default Object: 20
Default Variation: 5
Point-by-point list attached
Counters Roll Over at:
Point Index Name/Description Roll Over value
0 TC 9999
1 BOC Settable up to 30000
2 Number of Thermal
Trip
9999
3 Authorised hot start
number
Settable up to 5
4 Authorised cold start
number
Settable up to 5
5 Total Number of
starts
9999
6 Total number of
emergency restarts
9999
 No Counters Reported
 Configurable (attach explanation)
 16 Bits
 32 Bits
 Other Value
 Point-by-point list attached
Sends Multi-Fragment Responses:

Yes

No
