2.3.4 View Records Menu
2.3.4.1 View Records Menu Contents
VIEW RECORDS
Menu to view Fault Record, Event Record, Maint Record and Alarm
record.
Fault Record
This window is to view the Fault Record
Event Record
This window is to view the Event Record
Maint Record
This window is to view the Maint Record
Alarm Record
This window is to view the
Alarm Record
2.3.4.2 View Fault Records
VIEW RECORDS
Menu to view Fault Record, Event Record, Maint Record and Alarm
record.
Fault Record
This window shows the Fault Record
Fault Num = 1
This window shows the Fault Number of latest fault.
I>1: I<:
IN1>1: IN2>1: I2>1:
This window displays trip flag of stage 1: O/C, E/F-1 and E/F-2, Neg
Sequence O/C, Under Current, Thermal Trip.
Note: This window is seen when relay operates for respective protection
function.
