8 PROTECTION TIMING CHECKS
There is no need to check every protection function. Only one protection function needs to be checked as the
purpose is to v
erify the timing on the processor is functioning correctly.
8.1 BYPASSING THE ALL POLE DEAD BLOCKING CONDITION
Some protection functions and control functions are blocked when all poles are dead. When these conditions are
met
, an All Poles Dead signal is asserted, blocking the said conditions. If you wish to test these these elements
during commissioning, you must bypass this blocking condition. You can do this by modifying the default PSL,
placing a NOT gate between the CB1 Closed signal and opto-input 7, so that when this input is not energised, CB1
is assumed to be closed.
8.2 OVERCURRENT CHECK
If the overcurrent protection function is being used, test the overcurrent protection for stage 1.
1.
Check for any possible dependency conditions and simulate as appropriate.
2. In the CONFIGURATION column, disable all protection elements other than the one being tested.
3. Make a note of which elements need to be re-enabled after testing.
4. Connect the test circuit.
5. Perform the test.
6. Check the operating time.
8.3 CONNECTING THE TEST CIRCUIT
1. Use the PSL to determine which output relay will operate when an overcurrent trip occurs.
2.
Use the output relay assigned to Trip Output A.
3. Use the PSL to map the protection stage under test directly to an output relay.
Note:
If using the default PSL, use output relay 3 as this is already mapped to the DDB signal Trip Command Out.
Note:
If the timer does not st
op when the current is applied and stage 1 has been set for directional operation, the connections may
be incorrect for the direction of operation set. Try again with the current connections reversed.
8.4 PERFORMING THE TEST
1. Ensure that the timer is reset.
2.
Apply a current of twice the setting shown in the I>1 Current Set cell in the OVERCURRENT column.
3. Note the time displayed when the timer stops.
4. Check that the red trip LED has illuminated.
8.5 CHECK THE OPERATING TIME
Check that the operating time recorded by the timer is within the range shown below.
For all characteristics, allow
ance must be made for the accuracy of the test equipment being used.
P64x Chapter 19 - Commissioning Instructions
P64x-TM-EN-1.3 431
