7
Power Cord
(If Used)
Insulation
Blanket
Water
Line
House
Wiring
Drain
Hose
Maximum
Drain Hose
Length 10'
Installation Instructions
STEP 8 SLIDE DISHWASHER
PARTIALLY INTO CABINET
DO NOT PUSH AGAINST FRONT PANEL WITH KNEES.
DAMAGE WILL OCCUR.
• Slide dishwasher into the opening a few inches at a time.
• As you proceed, pull the drain hose through the
opening under the sink. Stop pushing when the dish-
washer is a few inches forward of adjacent cabinetry.
• Make sure drain hose is not kinked under the dish-
washer and there is no interference with the water
line and wiring or any other component.
TIP: Position water line and house wiring on the fl oor
to avoid interference with base of dishwasher.
STEP 7 INSERT DRAIN HOSE
THROUGH CABINET
• Upright the dishwasher and position in front of the
opening. Insert drain hose into cabinet wall hole.
If a power cord is used, guide the end through a
separate hole.
STEP 6 INSTALL DRAIN HOSE
• Install the screw type hose clamps to the drain hose.
hose, then tighten the screw type hose hose.
Do Not Push Against
Front Door Panel With
Knee. Damage to The
Door Panel Will Occur.
The drain hose installation hole
• Install the drain hose to the drain hose installation

GE PDT660SSFSS Specifications

General

Door color	Stainless steel
Control type	Touch
Built-in display	Yes
Appliance placement	Undercounter
Noise level	45 dB
Delay start (max)	9 h
Dishwashing programs	Auto, Glass/delicate, Eco, Normal, Pre-wash, Quick
Number of place settings	16 place settings
Number of washing programs	6
Current	9.9 A
AC input voltage	120 V
AC input frequency	60 Hz
Water consumption per cycle	- L
Energy consumption per cycle	- kWh
Annual energy consumption	249 kWh
Sustainability certificates	ENERGY STAR
Package weight	45360 g

Weight and Dimensions

Depth	609.6 mm
Width	603.3 mm
Height	847.7 mm
