4.3 Initial Startup
You will need the following:
• Safety Extra Low Voltage (SELV) and Limited Energy Circuit or
SELV
and Class 2 dc power supply.
• The power terminal block is supplied with the product. For voltage and requirements, refer to the Input Power
specifications in the table, General Specifications.
• The mating power terminal block supports stranded 30 to 14 AWG
(0.05 to 2.00 mm
2
) wires. The user calculates proper gauge wiring for current carrying capacity and loss according to
local regulations.
• At a minimum, the cable must be rated for 75°C (167 °F) or more.
• USB-compatible keyboard (optional)
• USB-compatible mouse (optional)
4.3.1 Connecting Input Power
➢ To connect input power
1. Verify that the power cable is not energized.
2. Loosen the screw clamps on the mating power connector.
3. Strip the insulation from the power cables.
4. Secure the power cable to the mating connector, noting polarity, and
tighten the screw clamps. The torque for the attaching screws is 0.3 Nm
(2.66
in-lb).
5. Apply dc power to the unit. During normal startup and operation, the
QuickPanel
+
status LED indicator displays as follows:
M2
.
5
Mounting
clamps
FG
M2
Screw
clamps
• Solid amber while the QuickPanel
+
is starting up
• Solid green during normal operation
6. Once power is applied, the QuickPanel
+
begins initializing. The
splash screen is the initial display.
➢ To skip running any programs included in the StartUp folder: tap
Don’t run Startup programs. The Microsoft Windows Embedded
Compact 7 operating system starts automatically.
GND +24 V dc
Power Connector
