3.9.1 Firmware Upgrade
Note This utility operates similar to the QuickPanel
+
Update Tool, which comes with the OS image upgrade binaries.
The operator can continue to use the QuickPanel
+
Update Tool to use the DIP Switch feature.
The Firmware Upgrade utility setting enables operators to upgrade the firmware. Firmware updates are not supported
over
Ethernet or Serial interfaces. Insert the media (SD Card) containing the required files for firmware upgrade and perform
the following procedure.
Note Make sure the copy of required binaries to the SD card is not within a folder.
Note The firmware package contains encrypted .nbo files. Use the PreUpdate.exe tool to decrypt the .nbo files before
using them for upgrade.
After a firmware upgrade, which refreshes the device fresh, the user must download the project again and install
their own tools (including third party tools) on the device.
Note It is recommended that the user back up any important data prior to firmware upgrade so that they can replace
the data after firmware upgrade if necessary.
If the current firmware build version on the QuickPanel
+
is any of the following, refer
to the section Firmware Upgrade for Specific Build Version:
• Build 3 or below for IC755CxS06RDx
(6” Display)
• Build 23 or below for IC755CxW07CDx
Attention
(7” Display)
• Build 14 or below for
IC755CxS10CDx
(10" Display), IC755CxS12CDx
(12” Display), and IC755CxS15CDx
(15” Display)
