Chapter 1. Introduction
14 PACSystems* RX3i PROFINET IO-Scanner User Manual GFK-2737F
Catalog Number
Module Description
Distinguishing Classes
1
IC694ALG220
4-Point Analog Voltage Input
ALG IN 4
IC694ALG221
4-Point Analog Current Input
ALG IN 4
IC694ALG222
16-Point Analog Voltage Input
ALG IN 16
IC694ALG223
16-Point Analog Current Input
ALG IN 16
IC695ALG106
6-Point Isolated Analog Input Current/Voltage
3,4
none
IC695ALG112
12-Point Isolated Analog Current/Voltage Input
4
none
IC695ALG600
8-Point Universal Analog Input Module
4
none
IC695ALG608
8-Point Analog Input Current / Voltage Input
3, 4
none
IC695ALG616
16-Point Analog Current / Voltage Input
4
none
IC695ALG626
16-Point Analog Current / Voltage Input
4
(HART
5
Support)
none
IC695ALG628
8-Point Analog Current / Voltage Input
3, 4
(HART
5
Support)
none
Analog Output Modules
IC693ALG390
2-Point Analog Voltage Output
ALG OUT 2
IC693ALG391
2-Point Analog Current Output
ALG OUT 2
IC693ALG392
8-Point Analog Current / Voltage Output
ALG OUT 8
IC694ALG390
2-Point Analog Voltage Output
ALG OUT 2
IC694ALG391
2-Point Analog Current Output
ALG OUT 2
IC694ALG392
8-Point Analog Current / Voltage Output
ALG OUT 8
IC695ALG704
4-Point Analog Current / Voltage Output
3, 4
none
IC695ALG708
8-Point Analog Current / Voltage Output
4
none
IC695ALG728
8-Point Analog Current / Voltage Output
4
(HART
5
Support)
none
IC695ALG808
8-Point Isolated Analog Current / Voltage Output
4
none
Analog Mixed Modules
IC693ALG442
4-Input / 2-Output, Current / Voltage
ALG IN 4, ALG OUT 2
IC694ALG442
4-Input / 2-Output, Current / Voltage
ALG IN 4, ALG OUT 2
RTD Input Modules
IC695ALG508
8-Channel Isolated RTD Input
4
none
Thermocouple Input Modules
IC695ALG312
12-Point Isolated Thermocouple Input
3, 4
none
IC695ALG412
12-Point Isolated High Speed Thermocouple Input
3, 4
none
3
PNS001 firmware version 2.40 required for this product.
4
PNS001 currently does not support Fault Reporting or Interrupts from this module.
5
PNS001 firmware version 2.30 supports the HART Pass Through capabilities of this module. HART-compatible PNC001 and CPU
versions are also required.
