GE Healthcare SENOGRAPHE DMR+
REV 1 pim 5128706–1–100
3–3
SECTION 1
DIMENSIONS
TABLE 3–1
PRODUCT PHYSICAL CHARACTERISTICS
  


1
&& !feet*
$)1
&& !feet*
$1
&& !feet*
( !pounds*
Gantry 1200 (3.94’) 540 (1.77’) 1710/2410 (5.61/7.91’) 280 (617.3) 3–1
Console 550 (1.81’) 180 (0.59’) 85 (0.28’) 3(6.6) –
Generator
cabinet
562 (1.84’) 431 (1.41’) 917 (3.01’) 105 (231.5) 3–2
Rad shield
screen + console
700 (2.29’) 490 (1.60’) 2200 (7.21’) 90 (155) 3–3
Accessories
storage device
900 (2.95’) 500 (1.61’) 890 (2.92’) 50 (110.2) 3–7
Stereotix 2
positioner
345 (1.13’) 430 (1.43’) 295 (0.97’) 8(17.4) 3–7
Stereotix 2
console
480 (1.58’) 380 (1.25’) 210 (0.69’) 6(13.2) 3–7
DATAFLASH
option
400 (1.31’) 330 (1.08’) 395 (1.29’) 11.4 (25.1) 3–8
Gantry Dimensional (see Illustration 3–1)
(1) Three anchoring points, GEMS provides three 10–mm dia screws with three Hilti HDE
M10 for use in concrete slab construction only (For HDE M10 bolts, drill a 62–mm deep
18–mm dia hole).
Anchoring components for other floor construction types must be supplied locally.
