GE SENOGRAPHE DMR+ Preinstallation Manual

ADDITIONAL PLANNING
AIDS
GE Healthcare SENOGRAPHE DMR+
REV 1 pim 5128706–1–100
4–2
ILLUSTRATION 4–1
INTERCONNECTION SCHEMATIC
A = Input voltage = 480 V single–phase.
B = Input voltage = 200/208/220/240/380/415 V single–phase.
6.5 m
21.33’
Dia = 35 mm 1.38”
4.8 m
15.75’
Dia = 8 mm 0.32”
10 m
33’
4 m
13.1’
STEREOTIX 2
(OPTION)
GEMS–E
SUPPLIED
CUSTOMER
SUPPLIED
G
E
N
E
R
A
T
O
R
2
1
B
9 m
36”
ALL CABLES LENGTHS INDICATED ARE USABLE LENGTHS
GANTRY
CONTROLLER
POSITIONER
CONTROLE
CONSOLE
DATAFLASH
(OPTION)
