Critical Power
Modifications reserved
Page 30/46
GE_UPS_OPM_SGS_ISG_10K_40K_0US_V070.docx
Installation Guide SG Series 10-20-30-40 UL S
Notices for installation
Fig. 3.8.4-2 Interconnection links BR1, BR2 and BR3 of SG Series 10 & 20
For separate Bypass and Rectifier Input configuration, the interconnection links BR1, BR2 and BR3
MUST BE REMOVED.
SGT5000_010-020_UPS BR1-2-3_01
X2
X1
BR2BR1
BR3
