GE UR series

GE Multilin L60 Line Phase Comparison System B-31
APPENDIX B B.4 MEMORY MAPPING
B
Continuous Monitor (Read/Write Setting)
6130 Continuous Monitor Function 0 to 1 --- 1 F102 0 (Disabled)
6131 Continuous Monitor I OP 0 to 65535 --- 1 F300 0
6132 Continuous Monitor I Supervision 0 to 65535 --- 1 F300 0
6133 Continuous Monitor V OP 0 to 65535 --- 1 F300 0
6134 Continuous Monitor V Supervision 0 to 65535 --- 1 F300 0
6135 Continuous Monitor Target 0 to 2 --- 1 F109 0 (Self-reset)
6136 Continuous Monitor Events 0 to 1 --- 1 F102 0 (Disabled)
Negative Sequence Time Overcurrent (Read/Write Grouped Setting) (2 modules)
6300 Negative Sequence Time Overcurrent 1 Function 0 to 1 --- 1 F102 0 (Disabled)
6301 Negative Sequence Time Overcurrent 1 Signal Source 0 to 5 --- 1 F167 0 (SRC 1)
6302 Negative Sequence Time Overcurrent 1 Pickup 0 to 30 pu 0.001 F001 1000
6303 Negative Sequence Time Overcurrent 1 Curve 0 to 16 --- 1 F103 0 (IEEE Mod Inv)
6304 Negative Sequence Time Overcurrent 1 Multiplier 0 to 600 --- 0.01 F001 100
6305 Negative Sequence Time Overcurrent 1 Reset 0 to 1 --- 1 F104 0 (Instantaneous)
6306 Negative Sequence Time Overcurrent 1 Block 0 to 65535 --- 1 F300 0
6307 Negative Sequence Time Overcurrent 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
6308 Negative Sequence Time Overcurrent 1 Events 0 to 1 --- 1 F102 0 (Disabled)
6309 Reserved (7 items) 0 to 1 --- 1 F001 0
6310 ...Repeated for Negative Sequence Time Overcurrent 2
Negative Sequence Instantaneous Overcurrent (Read/Write Grouped Setting) (2 modules)
6400 Negative Sequence Instantaneous OC 1 Function 0 to 1 --- 1 F102 0 (Disabled)
6401 Negative Sequence Instantaneous OC 1 Signal Source 0 to 5 --- 1 F167 0 (SRC 1)
6402 Negative Sequence Instantaneous Overcurrent 1 Pickup 0 to 30 pu 0.001 F001 1000
6403 Negative Sequence Instantaneous Overcurrent 1 Delay 0 to 600 s 0.01 F001 0
6404 Negative Sequence Instantaneous OC 1 Reset Delay 0 to 600 s 0.01 F001 0
6405 Negative Sequence Instantaneous Overcurrent 1 Block 0 to 65535 --- 1 F300 0
6406 Negative Sequence Instantaneous Overcurrent 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
6407 Negative Sequence Instantaneous Overcurrent 1 Events 0 to 1 --- 1 F102 0 (Disabled)
6408 Reserved (8 items) 0 to 1 --- 1 F001 0
6410 ...Repeated for Negative Sequence Instantaneous OC 2
Negative Sequence Overvoltage (Read/Write Grouped Setting)
64A0 Negative Sequence Overvoltage Function 0 to 1 --- 1 F102 0 (Disabled)
64A1 Negative Sequence Overvoltage Source 0 to 5 --- 1 F167 0 (SRC 1)
64A2 Negative Sequence Overvoltage Pickup 0 to 1.25 pu 0.001 F001 300
64A3 Negative Sequence Overvoltage Pickup Delay 0 to 600 s 0.01 F001 50
64A4 Negative Sequence Overvoltage Reset Delay 0 to 600 s 0.01 F001 50
64A5 Negative Sequence Overvoltage Block 0 to 65535 --- 1 F300 0
64A6 Negative Sequence Overvoltage Target 0 to 2 --- 1 F109 0 (Self-reset)
64A7 Negative Sequence Overvoltage Events 0 to 1 --- 1 F102 0 (Disabled)
Power Swing Detect (Read/Write Grouped Setting)
65C0 Power Swing Detect Function 0 to 1 --- 1 F102 0 (Disabled)
65C1 Power Swing Detect Source 0 to 5 --- 1 F167 0 (SRC 1)
65C2 Power Swing Detect Mode 0 to 1 --- 1 F513 0 (Two Step)
65C3 Power Swing Detect Supervision 0.05 to 30 pu 0.001 F001 600
65C4 Power Swing Detect Forward Reach 0.1 to 500 ohms 0.01 F001 5000
65C5 Power Swing Detect Forward RCA 40 to 90 degrees 1 F001 75
65C6 Power Swing Detect Reverse Reach 0.1 to 500 ohms 0.01 F001 5000
65C7 Power Swing Detect Reverse RCA 40 to 90 degrees 1 F001 75
65C8 Power Swing Detect Outer Limit Angle 40 to 140 degrees 1 F001 120
65C9 Power Swing Detect Middle Limit Angle 40 to 140 degrees 1 F001 90
65CA Power Swing Detect Inner Limit Angle 40 to 140 degrees 1 F001 60
65CB Power Swing Detect Delay 1 Pickup 0 to 65.535 s 0.001 F001 30
65CC Power Swing Detect Delay 1 Reset 0 to 65.535 s 0.001 F001 50
Table B–9: MODBUS MEMORY MAP (Sheet 23 of 55)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
