Vscan Air Battery
Vscan Air – User Manual 3-21
Direction GP092020-1EN Rev 18
Vscan Air CL is OFF
A short press (<1 sec) on the power button while the Vscan Air
CL probe is off will show the battery charge status via the LED
lights.
Figure 3-10. LED states when Vscan Air CL is OFF
- No li
ght indicates a Vscan Air CL charge level in the rang
e
<8% and
probe will need to charge above 8% to be powered on.
- A st
eady yellow light on both LEDs indicates a Vscan Air CL
charge level in the range 8-90%.
- A st
eady green light on both LEDs indicates a Vscan Air CL
charge level in the range 90-100%.
1. Battery level 8-90%
2. Fully
charged
